Bring Large Format 3D Printing In-House

FORM 3L

Scale up your in-house print production with the Form 3L, an easy-to-use large-format 3D printer for reliable production of industrial-quality parts.

Small Details, Big Results

Eliminate the turnaround time of outsourcing or the manual work of assembly for large scale 3D prints. The Form 3L offers a massive build volume at an unprecedented value.

SPECIFICATIONS HARDWARE

Dimensions :

77.5 × 52 × 73.5 cm ( 30.5 × 20.5 × 28.9 in )



Weight:



54 kg (120 lbs)



Operating Temperature :



Auto-heats to 35 °C
Auto-heats to 95 °F

Temperature Control :



Air-heated print chamber

Power Requirements :



100–240 VAC
7.5 A
50/60 Hz
650 W

Laser Specifications :



2 Light Processing Units
EN 60825-1:2007 certified
Class 1 Laser Product
405 nm wavelength
250 mW power
85 micron (0.0033 in) laser spot







Connectivity :

Wi-Fi (2.4, 5 GHz)
Ethernet (1000 Mbit)
USB 2.0



Printer control :



5.5" interactive touchscreen 1280 × 720 resolution

Incredible Part Quality

Stop sacrificing on quality for larger prints. The Form 3L provides the incredible surface finish and fine detail that stereolithography 3D printing is known for.




25μm ( XY Resolution )

250mW (Laser Power )

PRINTING PROPERTIES

Technology :

Low Force Stereolithography (LFS)™



Biocompatible Materials:



No



Resin Fill System :



Automated







Build Volume :



33.5 × 20 × 30 cm ( 13.2 × 7.9 × 11.8 in )



Layer Thickness (Axis Resolution) :



25 – 300 microns
.001 – .012 in



Laser Spot Size :



85 microns (0.0033 in )







Supports :

Auto-Generated
Light-Touch Removal

Resin Cartridges :

2

Form 3L

Flawless Prints, Every Time

3D Printer
